Continuous Liquid Solid Separation Centrifuge with 2 - 7um Separation Point
Brief Introduction
Mud Decanter centrifuge is the fourth solids control equipment in treating drilling fluid. It’s used to separate suspension liquid by adopting principle of centrifugal sedimentation. According to different rotary speed, it can be divided into middle speed centrifuge, high speed centrifuge and high speed frequency centrifuge. It mainly separates 2-7μm solid particles in drilling fluid. TR decanter centrifuge is widely used in oil & gas drilling, drilling waster management and sewage treatment.
TR Solids Control is a lead and professional manufacturer of decanter centrifuge. TR decanter centrifuge is high in recovery rate, effective in solids control and remarkable in the reduction of cost spent on drilling mud resupplying and management. Separation point of TR decanter centrifuge can meet as fine as 2~7 microns.
Main Advantages of TRLW Series Decanter Centrifuge
- Straight and cone section of the drum are made from 2205 duplex stainless steel material, adopt centrifugal casting process.
- Remaining components of the drum assembly are made from SS316L.
- Using imported SKF and NSK bearings to improve equipment stability and bearing life.
- Screw carrier adopts YG6 wear-resistant alloy sheet protection. With long life, easy maintenance and replacement.
- Frequency control facilitates customers to adjust speed at any time, meeting different working conditions.
- Drum assembly is protected with demountable support frame in transit, preventing damage to bearing.
- Schneider or Siemens electrical components. Current overload & mechanical limit switch dual protections.
- Diversion port of screw pusher and slag-drip opening of the drum are protected by replaceable wear-resistant alloy sleeve, delaying the service life and maintenance cycle.
Technical Data of TRLW Series Decanting Centrifuge
| Model | TRGLW355N-1 | TRGLW450N-2 | TRGLW450N-3 | TRGLW550N-1 |
| Bowl Diameter | 355mm (14inch) | 450mm (17.7inch) | 450mm (17.7inch) | 550mm (22inch) |
| Bowl Length | 1250mm(49.2inch) | 1250mm(49.2inch) | 1600(64inch) | 1800mm(49.2inch) |
| Max Capacity | 40m3/h | 60m3/h | 70m3/h | 90m3/h |
| Max Speed | 3800r/min | 3200r/min | 3200r/min | 3000r/min |
| Rotary Speed | 3200r/min | 3000r/min | 2800r/min | 2600r/min |
| G-Force | 3018 | 2578 | 2578 | 2711 |
| Separation | 2~5μm | 2~5μm | 2~5μm | 2~5μm |
| Main Drive | 30kW-4p | 30kW-4p | 45kW-4p | 55kW-4p |
| Back Drive | 7.5kW-4p | 7.5kW-4p | 15kW-4p | 22kW-4p |
| Weight | 2950kg | 3200kg | 4500kg | 5800kg |
| Dimension | 2850X1860X1250 | 2600X1860X1250 | 2950X1860X1250 | 3250X1960X1350 |
(Note: Rotary speed can be adjustable as per user's requirements)
Competitive Advantages
1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.
Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
